1FL6044-1AF61-2AB1
Siemens SIMOTICS S-1FL6 Servo Motor – 1FL6044-1AF61-2AB1
Maan Electro Controls – Siemens Servo Motor Supplier & Stockist
The Siemens SIMOTICS S-1FL6 Servo Motor – 1FL6044-1AF61-2AB1 is a compact and high-performance servo motor designed for precise motion control, positioning, machine automation, and industrial servo applications.
This SIMOTICS S-1FL6 motor operates at 3AC 400 V with a rated power of 0.75 kW and rated speed of 3000 rpm. It provides a stall torque M0 of 3.5 Nm and rated torque MN of 2.39 Nm.
The motor features a 45 mm shaft height, incremental encoder with 2500 increments/revolution, feather key, holding brake, and IP65 degree of protection with sealing ring. It is compatible with SINAMICS V70 and SINAMICS V90 converters, making it suitable for integrated Siemens servo-drive systems.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SIMOTICS S-1FL6
· Motor Type: Servo Motor
· Order Number: 1FL6044-1AF61-2AB1
· Operating Voltage: 3AC 400 V
· Rated Power: 0.75 kW
· Rated Speed: 3000 rpm
· Stall Torque M0: 3.5 Nm
· Rated Torque MN: 2.39 Nm
· Shaft Height: 45 mm
· Encoder Type: Incremental Encoder
· Encoder Resolution: 2500 increments/rev.
· Shaft: With Feather Key
· Holding Brake: Yes
· Degree of Protection: IP65
· Sealing: With Sealing Ring
· Connection: Angle Plug
· Tolerance: N
· Compatible Converters: SINAMICS V70 & V90
· Application: Precision motion control and industrial automation
TECHNICAL FEATURES
1. 0.75 kW Servo Motor
The 1FL6044-1AF61-2AB1 provides a rated power of 0.75 kW, making it suitable for compact and medium-duty precision motion applications.
2. 3000 rpm Rated Speed
With a rated speed of 3000 rpm, the motor is designed for dynamic motion applications requiring controlled and accurate rotary movement.
3. High Torque Performance
The motor provides a 3.5 Nm stall torque (M0) and 2.39 Nm rated torque (MN) for reliable machine-axis movement and controlled acceleration.
4. 2500 Increments/Rev. Incremental Encoder
The integrated incremental encoder with 2500 increments/revolution provides position and speed feedback to the servo drive for precise motion-control operation.
5. Holding Brake
The motor incorporates a holding brake, making it suitable for applications where the motor shaft needs to be held securely when the motor is stopped or de-energized.
6. IP65 Protection
With IP65 degree of protection and sealing ring, the motor is designed for industrial environments where protection against dust and water jets is required.
7. Feather-Key Shaft
The motor features a feather-key shaft, supporting secure mechanical coupling with compatible machine components, gearboxes, couplings, and transmission elements.
8. SINAMICS V70 & V90 Compatibility
The 1FL6044-1AF61-2AB1 is compatible with Siemens SINAMICS V70 and SINAMICS V90 converters, allowing it to be integrated into Siemens servo motion-control systems.
