1FL6044-1AF61-2LA1
SIEMENS SIMOTICS S-1FL6 Servo Motor – 1FL6044-1AF61-2LA1
The Siemens SIMOTICS S-1FL6 1FL6044-1AF61-2LA1 is a compact and high-performance servo motor designed for precise motion control applications. It operates on 3-phase 400 V AC, delivers 0.75 kW rated power, and provides a rated speed of 3000 rpm. With a 20-bit absolute encoder and 12-bit multi-turn capability, this motor offers accurate position feedback for demanding automation and positioning applications.
PRODUCT SPECIFICATIONS
Product : SIMOTICS S-1FL6 Servo Motor
Article Number : 1FL6044-1AF61-2LA1
Rated Voltage : 3AC 400 V
Rated Power : 0.75 kW
Rated Speed : 3000 rpm
Rated Torque (MN) : 2.39 Nm
Standstill Torque (M0) : 3.5 Nm
Shaft Height : 45 mm
Encoder : Absolute Encoder
Encoder Resolution : 20-bit
Multi-turn Resolution : 12-bit
Shaft : Feather key
Brake : Without holding brake
Protection Rating : IP65
Connector : Angle plug
Tolerance: N
Compatibility : SINAMICS V70 / V90
Motor Series : SIMOTICS S-1FL6
BENEFITS
High-Precision Positioning:
The 20-bit absolute encoder provides detailed position feedback for accurate motion control.
Reliable Servo Performance:
The combination of 0.75 kW power, 3000 rpm speed and 2.39 Nm rated torque supports responsive machine-axis operation.
Compact Machine Integration:
The 45 mm shaft height and angle connector configuration make the motor suitable for space-conscious machine designs.
Industrial Protection:
The IP65 enclosure rating provides protection suitable for many demanding industrial environments.
Multi-Turn Position Feedback:
The 12-bit multi-turn capability enables the motor to retain positional information across multiple revolutions.
SINAMICS Compatibility:
The motor is designed for use with SINAMICS V70 and V90 servo drive systems, supporting coordinated Siemens motion-control solutions.
