1FL6064-1AC61-2AB1
Siemens 1FL6064-1AC61-2AB1 SIMOTICS S-1FL6 Servo Motor
The Siemens SIMOTICS S-1FL6 1FL6064-1AC61-2AB1 is a 1.5 kW servo motor designed for high-precision industrial motion control applications. This motor operates at 3AC 400 V with a rated speed of 2000 rpm, providing 8 Nm stall torque (M0) and 7.16 Nm rated torque (MN).
The motor incorporates a 2500 incremental encoder for accurate speed and position feedback and is equipped with a holding brake for applications where the motor shaft needs to be securely held when the drive is disabled.
With a 65 mm shaft height, feather-key shaft, angle plug, and IP65 protection with sealing ring, the motor is designed for reliable integration into industrial machines and automated production systems.
TECHNICAL SPECIFICATIONS
Manufacturer : Siemens
Product Family : SIMOTICS S-1FL6
Article Number : 1FL6064-1AC61-2AB1
Motor Type : Servo Motor
Operating Voltage : 3AC 400 V
Rated Power (Pn) : 1.5 kW
Rated Speed (Nn) : 2000 rpm
Stall Torque (M0) : 8 Nm
Rated Torque (MN) : 7.16 Nm
Shaft Height : 65 mm
Encoder Type : Incremental Encoder
Encoder Resolution : 2500 incr./rev.
Shaft Design : Feather Key
Brake : Holding Brake
Connector : Angle Plug
Protection Rating : IP65
Sealing : Sealing Ring
PRODUCT BENEFITS
· 1.5 kW rated servo motor
· 3AC 400 V operating voltage
· 2000 rpm rated speed
· 8 Nm stall torque
· 7.16 Nm rated torque
· 65 mm shaft height
· 2500 incr./rev. incremental encoder
· Integrated holding brake
· Feather-key shaft
· Angle plug connection
· IP65 protection
· Sealing ring
· Compatible with SINAMICS V70
· Compatible with SINAMICS V90
· Suitable for industrial automation and OEM machinery
· Designed for precise servo motion applications
