1FL6096-1AC61-2AA1
Siemens SIMOTICS S-1FL6 7 kW Servo Motor – 1FL6096-1AC61-2AA1
The Siemens SIMOTICS S-1FL6 – 1FL6096-1AC61-2AA1 delivers 7 kW rated power at 2000 rpm, with 33.4 Nm rated torque and 40 Nm standstill torque. Designed for compatible SINAMICS V70 and V90 converters, this motor incorporates an incremental encoder with 2500 increments per revolution for motion feedback. It features a feather-key shaft, an angle plug, and IP65 protection with a sealing ring, and is supplied without a holding brake.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SIMOTICS S-1FL6
· Order Number: 1FL6096-1AC61-2AA1
· Product Type: Servo Motor
· Operating Voltage: 3 AC, 400 V
· Rated Power (Pn): 7 kW
· Rated Speed (Nn): 2000 rpm
· Standstill Torque (M0): 40 Nm
· Rated Torque (MN): 33.4 Nm
· Shaft Height: 90 mm
· Connector Style: Angle plug
· Encoder: Incremental, 2500 increments/revolution
· Shaft Design: With feather key
· Tolerance Class: N
· Holding Brake: Without holding brake
· Protection Rating: IP65 with sealing ring
· Compatible Converters: SINAMICS V70 & V90
HIGHLIGHTS
· Rated Operating Output: Provides 7 kW mechanical power at the specified rated operating point.
· Torque for Load Sizing: Offers 33.4 Nm rated torque and 40 Nm standstill torque for assessing application requirements.
· Incremental Encoder Feedback: Supplies movement feedback to a compatible converter for servo control.
· Keyed Mechanical Interface: Enables torque transfer through an appropriately matched coupling or transmission component.
· Angle Plug Connection: Provides an angled connector arrangement for planning motor cable routing.
APPLICATIONS
· Material Transfer: Drive suitably sized mechanisms that move components between machine stations.
· Packaging Axes: Support controlled feeding and indexing movements.
· Assembly Machinery: Operate axes requiring programmed motion and encoder feedback.
· Geared Drive Systems: Connect to a suitable gearbox to match the required output speed and torque.
