6ES7222-1BH32-0XB0 IN TIRUVANNAMALAI
Siemens SIMATIC S7-1200 SM 1222 Digital Output Module – 6ES7222-1BH32-0XB0
The Siemens SIMATIC S7-1200 SM 1222 Digital Output Module – 6ES7222-1BH32-0XB0 is a digital output expansion module designed for SIMATIC S7-1200 PLC systems. This SM 1222 module provides 16 digital outputs at 24 V DC, using transistor output technology with a 0.5 A output rating.
The module is suitable for S7-1200 automation systems where additional digital output channels are required for controlling compatible field devices. It can be used for applications involving actuators, valves, contactors, relays, indicators, solenoids, and other suitable 24 V DC control loads.
With its 16-channel digital output configuration, the 6ES7222-1BH32-0XB0 provides a practical solution for expanding PLC output capacity in machine automation, OEM machinery, production systems, industrial control panels, and factory automation applications.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SIMATIC S7-1200
· Module: SM 1222
· Module Type: Digital Output Module
· Order Number: 6ES7222-1BH32-0XB0
· Digital Outputs: 16 DO
· Output Voltage: 24 V DC
· Output Technology: Transistor
· Output Rating: 0.5 A
· Application: Digital Output Expansion & Industrial Automation
TECHNICAL FEATURES
1. SIMATIC S7-1200 SM 1222
The SM 1222 provides additional digital output capacity for Siemens S7-1200 PLC systems, allowing more actuators and control devices to be operated from the PLC architecture.
2. 16 Digital Outputs
The module provides 16 digital output channels, making it suitable for automation applications requiring multiple actuator and device connections.
3. 24 V DC Output
The digital outputs operate at 24 V DC, suitable for compatible DC control circuits commonly used in industrial automation and machine control.
4. Transistor Output Technology
The module uses transistor outputs for switching compatible DC loads in PLC-based automation applications.
5. 0.5 A Output Rating
Each digital output is rated at 0.5 A, supporting suitable 24 V DC loads used for industrial control and machine automation.
6. High-Channel Output Expansion
With 16 digital outputs, the SM 1222 is suitable for S7-1200 applications where a larger number of output signals are required.
7. S7-1200 Integration
The 6ES7222-1BH32-0XB0 can be integrated into compatible S7-1200 PLC architectures to provide additional digital output channels.
