6ES7288-2DE08-0AA0
The Siemens SIMATIC S7-200 SMART Digital Input Module SM DI08 (6ES7288-2DE08-0AA0) is an expansion module designed to increase the digital input capacity of an S7-200 SMART PLC system. It provides 8 digital inputs for 24 V DC signals and supports Sink/Source wiring, making it suitable for different industrial control and automation configurations.
The module receives ON/OFF signals from field devices such as proximity sensors, photoelectric sensors, limit switches, push buttons, selector switches, safety-related auxiliary contacts, and machine status signals. These signals are transferred to the PLC CPU, where the control program processes them to operate motors, valves, cylinders, conveyors, relays, and other automation equipment.
The SM DI08 works as the communication point between field input devices and the S7-200 SMART PLC:
Sensor / Switch → SM DI08 Digital Input → S7-200 SMART CPU → PLC Program → Output Device
With 8 × 24 V DC digital inputs, the module helps expand the PLC's input points when the standard CPU I/O is not sufficient for a machine or automation application.
Main Features
· Product: SIMATIC S7-200 SMART Digital Input Module
· Model: SM DI08
· Article Number: 6ES7288-2DE08-0AA0
· Digital Inputs: 8 DI
· Input Voltage: 24 V DC
· Input Type: Digital
· Wiring Capability: Sink/Source
· Suitable for machine automation and control applications
· Expands the digital input capacity of an S7-200 SMART PLC
· Designed for integration with SIMATIC S7-200 SMART systems
· Useful for monitoring multiple ON/OFF field signals
Typical Applications
· Conveyor automation
· Packaging machines
· Material handling systems
· Assembly machines
· Filling and processing machines
· Pump control systems
· Machine tools
· Textile machinery
· Industrial production lines
· OEM machine automation
· Control panels
· Sensor monitoring systems
· Automated manufacturing equipment
Benefits
· 8 additional digital input points
· Supports 24 V DC industrial signals
· Flexible Sink/Source input configuration
· Simplifies connection of multiple field sensors and switches
· Helps expand the I/O capability of an S7-200 SMART PLC
· Suitable for compact machine-control applications
· Enables reliable monitoring of field device
· Useful for OEMs, panel builders and system integrators
