6ES7288-2DT16-0AA0
The Siemens 6ES7288-2DT16-0AA0 is a SIMATIC S7-200 SMART SM DT16 Digital I/O Expansion Module designed to extend the digital signal-handling capability of compatible S7-200 SMART PLC systems. It combines 8 digital inputs and 8 digital transistor outputs in one module, making it suitable for machine automation systems that need both field-signal monitoring and DC output control.
With 24 V DC digital inputs supporting Sink/Source configuration and 0.75 A transistor outputs, the module provides a practical interface between the PLC and industrial sensors, switches, actuators, solenoid valves, indicators and other compatible control devices.
TECHNICAL HIGHLIGHTS
· Article Number: 6ES7288-2DT16-0AA0
· Product Family: SIMATIC S7-200 SMART
· Module Designation: SM DT16
· I/O Type: Mixed Digital I/O
· Digital Input Channels: 8
· Digital Input Voltage: 24 V DC
· Input Configuration: Sink/Source
· Digital Output Channels: 8
· Output Technology: Transistor
· Output Rating: 0.75 A
· Application: PLC Digital I/O Expansion
Benefits of Siemens 6ES7288-2DT16-0AA0
· Combined 8DI + 8DO design – Provides both digital input and output functionality in one expansion module.
· Flexible 24 V DC inputs – 8 digital inputs support common industrial field signals.
· Sink/Source compatibility – Provides flexibility when designing input wiring for different machine-control applications.
· 0.75 A transistor outputs – Supports switching of compatible 24 V DC loads and control devices.
· Efficient I/O expansion – Adds 16 digital channels to a compatible S7-200 SMART automation system.
· Ideal for sensor and actuator control – Allows the PLC to monitor field devices and control connected outputs through the same module.
· Simplifies panel architecture – A mixed I/O module can reduce the requirement for separate digital input and output modules.
· Supports compact machine design – Suitable for automation panels where space and I/O efficiency are important.
· Suitable for OEM applications – Useful for customized machines, packaging equipment, conveyors and assembly systems.
· Easy system integration – Designed for integration within the Siemens S7-200 SMART PLC platform.
· Reliable transistor switching – Appropriate for compatible DC switching applications requiring fast electronic output control.
· Improves I/O organization – Provides a structured interface between the PLC CPU and machine-level digital devices.
· Scalable automation solution – Helps expand PLC capabilities as additional sensors and actuators are introduced.
· Reduced module complexity – Combining inputs and outputs in one module can simplify overall I/O planning.
· Industrial automation ready – Suitable for machine control, material handling, production equipment and general factory automation.
