6ES7288-2DT32-0AA0
6ES7288-2DT32-0AA0 is a SIMATIC S7-200 SMART SM DT32 Digital I/O expansion module from Siemens, featuring 16 digital inputs and 16 digital transistor outputs. The module provides a total of 32 digital I/O points, with 24 V DC inputs supporting sink/source wiring and 0.75 A transistor outputs.
It is designed for expanding the digital I/O capacity of S7-200 SMART PLC-based automation systems and is well suited for machine automation, OEM equipment, conveyor systems, packaging machinery, assembly lines, material handling and industrial control panels.
PRODUCT IDENTIFICATION
Siemens Article Number : 6ES7288-2DT32-0AA0
Product Series : SIMATIC S7-200 SMART
Module Type : SM DT32
Module Category : Digital I/O Expansion Module
Total Digital I/O : 32 points
Digital Inputs : 16 DI
Input Voltage : 24 V DC
Input Configuration : Sink/Source
Digital Outputs : 16 DO
Output Type : Transistor
Output Rating : 0.75 A
Application : PLC Digital I/O Expansion
FEATURES
High Digital I/O Density
Provides 32 digital channels in one module, combining 16 inputs and 16 outputs.
24 V DC Digital Inputs
Designed for common industrial 24 V DC control and sensing circuits.
Sink/Source Inputs
Provides flexibility for connecting different types of digital field wiring.
Transistor Outputs
16 transistor outputs are suitable for repeated switching in machine automation applications.
0.75 A Output Capability
Each digital output is specified at 0.75 A, providing useful capacity for compatible DC loads.
S7-200 SMART Compatibility
Designed as an expansion solution for the SIMATIC S7-200 SMART PLC family.
Compact Automation Architecture
Helps machine builders increase I/O without unnecessarily increasing cabinet complexity.
