6ES7288-2DT32-0AA0
Siemens 6ES7288-2DT32-0AA0 – SIMATIC S7-200 SMART SM DT32 is a compact and high-density digital I/O expansion module designed for reliable machine automation and control applications. It provides 16 digital inputs and 16 digital transistor outputs, offering a total of 32 digital I/O channels in a single module.
The 16 digital inputs operate at 24 V DC and support Sink/Source configuration, allowing flexible connection of field devices such as proximity sensors, push buttons, limit switches, photoelectric sensors and other digital signals. The module also features 16 transistor outputs rated at 0.75 A, making it suitable for controlling 24 V DC loads such as relays, solenoid valves, indicator lamps and other machine actuators.
With its high I/O density, compact design and 24 V DC industrial interface, the SM DT32 helps simplify control-panel design while providing efficient signal handling for automated machinery. It is well suited for conveyor systems, packaging machines, assembly equipment, material handling, production lines and general industrial automation.
PRODUCT HIGHLIGHTS
- Siemens Article No.: 6ES7288-2DT32-0AA0
- Series: SIMATIC S7-200 SMART
- Module: SM DT32
- I/O Configuration: 16 DI + 16 DO
- Digital Inputs: 16 × 24 V DC
- Input Type: Sink/Source
- Digital Outputs: 16 × 24 V DC transistor outputs
- Output Rating: 0.75 A per output
- Supply Voltage: 24 V DC
- Permissible Supply Range: 20.4–28.8 V DC
- Input Characteristic: IEC 61131 Type 1
- Inputs arranged in groups: 2
- Compact module: approximately 70 × 100 × 81 mm
- Typical module weight: approximately 257 g
- Designed as an S7-200 SMART expansion module
BENEFITS
- 32 digital I/O points in one module
- 16 inputs + 16 outputs
- Flexible Sink/Source digital inputs
- 24 V DC industrial control voltage
- 0.75 A transistor outputs
- Suitable for fast and repetitive switching applications
- Reduces the need for multiple smaller I/O modules
- Compact design for control-panel installation
- Easy integration with S7-200 SMART PLC systems
- Useful for machines requiring a large number of discrete signals
- Helps simplify PLC panel architecture and field wiring
