6ES7512-1DM03-0AB0
Siemens 6ES7512-1DM03-0AB0 – SIMATIC ET 200SP CPU 1512SP-1 PN
The Siemens 6ES7512-1DM03-0AB0 is a SIMATIC DP CPU 1512SP-1 PN designed for the SIMATIC ET 200SP distributed automation system. It combines compact ET 200SP architecture with S7-1500 CPU performance for applications requiring fast processing, reliable PROFINET communication, and flexible distributed I/O integration.
This CPU provides 400 KB work memory for the user program and 2 MB for data, with approximately 6 ns bit performance. Its PROFINET IRT interface with an integrated 3-port switch supports high-speed industrial networking and distributed automation architectures.
The CPU is supplied with the 6ES7193-6PA00-0AA0 server module. A SIMATIC Memory Card is required, while BusAdapters are required for Port 1 and Port 2.
PRODUCT DETAILS
- Manufacturer: Siemens
- Product Family: SIMATIC ET 200SP
- Product Type: Distributed PLC CPU
- CPU: CPU 1512SP-1 PN
- Article Number: 6ES7512-1DM03-0AB0
- Automation Platform: SIMATIC ET 200SP
- CPU Class: S7-1500-based ET 200SP CPU
- Communication: PROFINET
- Network Technology: PROFINET IRT
- Integrated Switch: 3-port switch
- Bit Performance: Approx. 6 ns
- Program Work Memory: 400 KB
- Data Work Memory: 2 MB
- Memory Card: SIMATIC Memory Card required
- BusAdapter: Required for Port 1 and Port 2
- Server Module: 6ES7193-6PA00-0AA0 included
PRODUCT HIGHLIGHTS
· CPU 1512SP-1 PN for SIMATIC ET 200SP
· 400 KB work memory for program
· 2 MB work memory for data
· Approx. 6 ns bit performance
· PROFINET IRT interface
· Integrated 3-port switch
· Designed for distributed automation
· Compact ET 200SP controller architecture
· Server module included
· SIMATIC Memory Card required
· BusAdapter required for Port 1 and Port 2
Benefits of Siemens 6ES7512-1DM03-0AB0
· High-Speed PLC Processing – Approx. 6 ns bit performance supports fast execution of automation logic and machine-control sequences.
· Powerful Memory Capacity – Provides 400 KB work memory for programs and 2 MB for data, supporting demanding control applications.
· Compact ET 200SP Design – Delivers powerful PLC functionality in the compact SIMATIC ET 200SP platform, helping optimize control-panel space.
· PROFINET IRT Communication – Enables high-performance industrial communication with compatible PROFINET devices and distributed automation components.
· Integrated 3-Port Switch – Simplifies PROFINET network architecture and provides flexible connectivity within the automation system.
· Distributed I/O Architecture – Designed to work with ET 200SP modules, allowing I/O to be positioned closer to machines and field devices.
· Efficient Machine Automation – Suitable for fast and coordinated control of production machines, conveyors, packaging equipment and automated systems.
· Scalable Siemens Automation – Can be integrated with ET 200SP I/O, SIMATIC HMI, SINAMICS drives and PROFINET devices for complete automation solutions.
· OEM-Friendly Controller – Compact architecture and distributed I/O capability make it suitable for machine builders and OEM automation projects.
· Reduced Wiring Complexity – Distributed ET 200SP I/O can help organize field connections closer to the equipment, reducing lengthy control wiring.
· Suitable for Modular Machines – Supports automation architectures where individual machine sections or stations require distributed control and I/O.
· Reliable Industrial Networking – PROFINET-based communication provides a structured platform for connecting PLCs, I/O, HMIs and other automation devices.
· Flexible Application Design – The combination of processing performance, memory and distributed I/O makes the CPU suitable for a wide range of industrial control requirements.
· Siemens Automation Compatibility – Fits naturally into Siemens-based automation environments and can be used as part of a broader TIA Portal / SIMATIC solution.
