6ES7513-1AM03-0AB0 IN DURGAPUR
Siemens SIMATIC S7-1500 CPU 1513-1 PN – 6ES7513-1AM03-0AB0
The Siemens SIMATIC S7-1500 CPU 1513-1 PN – 6ES7513-1AM03-0AB0 is a central processing unit designed for advanced industrial automation, machine control, production systems, and PLC-based control architectures.
The CPU provides 600 KB of work memory for the program and 2.5 MB of work memory for data, supporting structured automation programs and application data processing. Its first communication interface is PROFINET IRT with an integrated 2-port switch, enabling connection to compatible PROFINET-based industrial automation networks.
With a specified 6 ns bit performance, the CPU 1513-1 PN is suitable for automation applications requiring fast and reliable PLC processing. A SIMATIC Memory Card is required for operation.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SIMATIC S7-1500
· Product Type: Central Processing Unit
· CPU Model: CPU 1513-1 PN
· Order Number: 6ES7513-1AM03-0AB0
· Work Memory for Program: 600 KB
· Work Memory for Data: 2.5 MB
· First Interface: PROFINET IRT
· Network Interface: 2-port switch
· Bit Performance: 6 ns
· Memory Requirement: SIMATIC Memory Card required
· Application: Industrial automation and PLC control
· Platform: SIMATIC S7-1500
TECHNICAL FEATURES
1. SIMATIC S7-1500 CPU 1513-1 PN
The CPU 1513-1 PN functions as the central processing unit of a SIMATIC S7-1500 automation system. It is designed to execute PLC control programs and coordinate connected automation components.
2. 600 KB Work Memory for Program
The CPU provides 600 KB of work memory for the program, supporting the execution of automation logic, machine sequences, control functions, and PLC application programs.
3. 2.5 MB Work Memory for Data
With 2.5 MB of work memory for data, the CPU provides dedicated capacity for application data used during automation processing.
4. PROFINET IRT Interface
The first interface of the 6ES7513-1AM03-0AB0 is PROFINET IRT, allowing the CPU to communicate with compatible industrial automation devices over a PROFINET network.
5. Integrated 2-Port Switch
The CPU features a 2-port switch within its PROFINET interface, supporting practical industrial network integration and device connectivity.
6. 6 ns Bit Performance
The specified 6 ns bit performance provides fast processing capability for PLC applications where responsive control and efficient program execution are important.
7. SIMATIC Memory Card Required
A SIMATIC Memory Card is required for operation of the CPU. The memory card provides the required storage medium for the SIMATIC S7-1500 CPU application.
8. Centralized PLC Control
The CPU can operate as the central controller within an S7-1500 automation architecture, coordinating I/O, HMI, communication and other compatible Siemens automation components.
