6ES7521-1BH00-0AB0
Siemens 6ES7521-1BH00-0AB0 — SIMATIC S7-1500 DI 16x24 V DC HF
6ES7521-1BH00-0AB0 is a SIMATIC S7-1500 digital input module designed for reliable and high-speed acquisition of 24 V DC field signals in industrial automation applications. The module provides 16 digital inputs, with high-speed input functionality, diagnostics, configurable input delay, and hardware interrupt capability.
PRODUCT DETAILS
· Product: SIMATIC S7-1500 Digital Input Module
· Order Number: 6ES7521-1BH00-0AB0
· Module Type: DI 16x24 V DC HF
· Number of Digital Inputs: 16
· Input Voltage: 24 V DC
· Input Arrangement: 16 channels in 1 group
· Input Type: Type 3 according to IEC 61131
· Input Delay: 0.05 to 20 ms
· High-Speed Function: HF digital input module
· Counter Function: 2 inputs can be used as counters
· Diagnostics: Integrated diagnostics
· Hardware Interrupts: Supported
· Front Connector: Ordered separately
· Connector Options: Screw terminals or push-in
· System: SIMATIC S7-1500
FEATURES
1. 16 Digital Inputs
Provides 16 individual 24 V DC digital input channels for connecting field devices such as proximity sensors, limit switches, push buttons, selector switches and other binary signals.
2. High-Speed Input Capability
The HF version supports fast signal acquisition with an adjustable input delay range of 0.05 to 20 ms, making it suitable for applications where signal response time is important.
3. Integrated Counter Function
Two of the inputs can be configured for counter applications, allowing the module to be used for counting pulses from suitable field devices.
4. Configurable Input Delay
The input delay can be configured between 0.05 ms and 20 ms, helping optimize signal processing according to the connected field device and application requirements.
5. Diagnostic Functions
Integrated diagnostics help identify module and channel-related conditions, supporting easier troubleshooting and maintenance.
6. Hardware Interrupt Support
Hardware interrupts allow the S7-1500 CPU to respond to selected input events without relying only on the normal cyclic program scan.
APPLICATIONS
The 6ES7521-1BH00-0AB0 can be used in:
· Machine automation
· Assembly and production lines
· Conveyor systems
· Packaging machinery
· Material handling systems
· Sensor monitoring
· Position detection
· Part counting
· Pulse counting applications
· Manufacturing automation
· Process-control systems
· Automated production equipment
· PLC-based control panels
