6ES7521-1BH10-0AA0
The Siemens SIMATIC S7-1500 6ES7521-1BH10-0AA0 is a 16-channel digital input module designed for 24 V DC signal acquisition in industrial automation applications. This DI 16x24 V DC BA module enables the S7-1500 PLC to receive digital signals from field devices such as proximity sensors, limit switches, push buttons, selector switches and other ON/OFF devices.
With 16 digital inputs arranged in one group, the module provides a practical solution for expanding PLC input capacity while maintaining straightforward field wiring. It features a typical input delay of 3.2 ms and Type 3 input characteristics according to IEC 61131. The supplied Push-in front connector supports convenient and efficient wiring during panel installation and maintenance.
PRODUCT TECHNICAL DATA
Order Number : 6ES7521-1BH10-0AA0
Product Family : SIMATIC S7-1500
Module Type : Digital Input Module
Input Configuration : DI 16x24 V DC BA
Number of Inputs : 16 Digital Inputs
Rated Input Voltage : 24 V DC
Channel Arrangement : 16 channels in groups of 16
Input Characteristic : Type 3
Standard : IEC 61131
Typical Input Delay : 3.2 ms
Front Connector : Push-in
Connector Included : Yes
Signal Type : Digital ON/OFF
PLC Platform : SIMATIC S7-1500
FEATURES
· 16 digital input channels
· Designed for 24 V DC signal acquisition
· 3.2 ms typical input delay
· IEC 61131 Type 3 input characteristics
· 16 inputs arranged in a single group
· Push-in front connector included
· Designed for SIMATIC S7-1500 PLC systems
· Convenient field wiring arrangement
· Suitable for machine and factory automation
· Supports expansion of digital PLC input capacity
APPLICATIONS
· Machine automation systems
· Manufacturing and assembly machines
· Conveyor and material-handling systems
· Packaging machinery
· Control panels
· Production lines
· Industrial monitoring systems
· Process automation applications
· Sensor-based machine control
· Factory automation systems
