Siemens SIMATIC S7-1500 Digital Output Module – 6ES7522-1BH01-0AB0
The Siemens SIMATIC S7-1500 Digital Output Module – 6ES7522-1BH01-0AB0 is a high-performance digital output module (DQ) designed for integration into SIMATIC S7-1500 automation systems. It provides 16 digital outputs for 24 V DC loads, with an output current capability of 0.5 A per channel, making it suitable for industrial machine control, actuator switching, automated production systems, and control-panel applications.
The module features 16 channels arranged in groups of 8, with a maximum load capacity of 4 A per group. It also provides single-channel diagnostics and a substitute value function, including a switching-cycle counter for connected actuators, supporting monitoring and maintenance functions in suitable automation applications.
The 6ES7522-1BH01-0AB0 additionally supports the safety-oriented shutdown of load groups up to SIL2 according to EN IEC 62061:2021 and Category 3 / PL d according to EN ISO 13849-1:2015, when implemented within an appropriate safety-oriented system architecture.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SIMATIC S7-1500
· Module Type: Digital Output Module
· Order Number: 6ES7522-1BH01-0AB0
· Output Type: DQ
· Digital Outputs: 16 channels
· Output Voltage: 24 V DC
· Output Current: 0.5 A per channel
· Channel Configuration: 16 channels in groups of 8
· Current per Group: 4 A
· Diagnostics: Single-channel diagnostics
· Substitute Value: Supported
· Actuator Monitoring: Switching-cycle counter for connected actuators
· Safety-Oriented Shutdown: Supported for load groups up to SIL2
· Safety Standard: EN IEC 62061:2021
· Performance Level: Category 3 / PL d
· Standard: EN ISO 13849-1:2015
· Front Connector: Ordered separately
· Connector Options: Screw terminal or Push-in
· System: SIMATIC S7-1500
· Location: Chennai, Tamil Nadu, India
BENEFITS
· 16 digital outputs for 24 V DC industrial loads.
· 0.5 A output current per channel.
· 4 A maximum per output group.
· Channels arranged in groups of 8.
· Single-channel diagnostics for improved troubleshooting.
· Substitute-value functionality for suitable operating conditions.
· Switching-cycle counter for connected actuators.
· Supports safety-oriented shutdown of load groups up to SIL2 under the specified standard.
· Supports Category 3 / PL d safety-oriented applications under the specified standard.
· Flexible screw-terminal or push-in front connector options.
· Suitable for high-density S7-1500 digital output applications.
· Designed for OEM, machine-building, and industrial automation systems.
