Siemens SIMATIC S7-1500 DQ 16x24 V DC/0.5A HF – 6ES7522-1BH01-0AB0
The Siemens SIMATIC S7-1500 Digital Output Module DQ 16x24 V DC/0.5A HF – 6ES7522-1BH01-0AB0 is a high-performance digital output module designed for industrial automation, machine control, manufacturing systems, production lines, control panels, and actuator control applications.
This 16-channel digital output module provides 24 V DC outputs with 0.5 A per channel and is arranged in groups of 8 channels. Each group supports up to 4 A, making the module suitable for controlling multiple connected actuators and digital loads within an S7-1500 automation system.
The module provides single-channel diagnostics, a substitute value function, and a switching cycle counter for connected actuators. It also supports the safety-oriented shutdown of load groups up to SIL2 according to EN IEC 62061:2021 and Category 3 / PL d according to EN ISO 13849-1:2015.
The front connector is ordered separately, with screw-terminal or push-in connection options available.
For automation projects in Surat, Gujarat, the 6ES7522-1BH01-0AB0 provides a flexible and high-function digital output solution for controlling industrial actuators and loads.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SIMATIC S7-1500
· Module Type: Digital Output Module
· Order Number: 6ES7522-1BH01-0AB0
· Module Designation: DQ 16x24 V DC/0.5A HF
· Digital Outputs: 16 channels
· Output Voltage: 24 V DC
· Output Current: 0.5 A per channel
· Channel Configuration: 16 channels in groups of 8
· Current per Group: 4 A
· Diagnostics: Single-channel diagnostics
· Substitute Value: Supported
· Actuator Monitoring: Switching cycle counter for connected actuators
· Safety Function: Safety-oriented shutdown of load groups
· Safety Level: Up to SIL2 according to EN IEC 62061:2021
· Performance Level: Category 3 / PL d according to EN ISO 13849-1:2015
· Front Connector: Ordered separately
· Connector Options: Screw terminals or push-in
· PLC Platform: SIMATIC S7-1500
· Application: Industrial automation and digital actuator control
BENEFITS
· Siemens SIMATIC S7-1500 high-performance digital output module
· 16 × 24 V DC digital outputs
· 0.5 A output current per channel
· 16 channels arranged in groups of 8
· 4 A per output group
· Single-channel diagnostics
· Substitute value functionality
· Switching cycle counter for connected actuators
· Supports safety-oriented load-group shutdown
· Supports applications up to SIL2
· Supports Category 3 / PL d applications according to the stated standards
· Suitable for industrial actuator control
· Compatible with S7-1500 PLC architecture
· Suitable for machine automation
· Useful for manufacturing and production systems
· Suitable for OEM machinery and control panels
· Flexible screw-terminal or push-in front connector options
