Siemens SIMATIC S7-1500 Digital Output Module – 6ES7522-1BH10-0AA0
The Siemens SIMATIC S7-1500 Digital Output Module – 6ES7522-1BH10-0AA0 is a compact and reliable digital output module designed for integration into SIMATIC S7-1500 PLC systems. It provides 16 digital outputs for 24 V DC signals, with an output current capability of 0.5 A per channel, making it suitable for industrial machine control, actuator switching, production automation, and control-panel applications.
The 6ES7522-1BH10-0AA0 provides 16 channels arranged in groups of 8, with a maximum permissible current of 4 A per group. The module also supports the safety-oriented shutdown of load groups up to SIL2 according to EN IEC 62061:2021 and Category 3 / PL d according to EN ISO 13849-1:2015, when used within an appropriately designed and validated safety-related system.
The module is supplied with a Push-in front connector, providing a convenient wiring solution for industrial control panels and machine automation systems.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SIMATIC S7-1500
· Module Type: Digital Output Module
· Order Number: 6ES7522-1BH10-0AA0
· Output Type: DQ
· Digital Outputs: 16 channels
· Output Voltage: 24 V DC
· Output Current: 0.5 A per channel
· Channel Configuration: 16 channels in groups of 8
· Current per Group: 4 A
· Safety-Oriented Shutdown: Supported
· Safety Integrity Level: Up to SIL2
· Safety Standard: EN IEC 62061:2021
· Performance Level: Category 3 / PL d
· Safety Standard: EN ISO 13849-1:2015
· Front Connector: Push-in
· Front Connector Included: Yes
· System: SIMATIC S7-1500
· Location: Pune, Maharashtra, India
BENEFITS
· 16 digital outputs for industrial automation applications.
· 24 V DC output voltage for compatible field devices.
· 0.5 A output current per channel.
· 4 A per output group.
· Channels organized in groups of 8.
· Supports safety-oriented load-group shutdown up to SIL2.
· Supports Category 3 / PL d safety-oriented applications.
· Designed according to the specified EN IEC 62061:2021 requirements.
· Supports the specified EN ISO 13849-1:2015 safety category.
· Push-in front connector included.
· Compact solution for S7-1500 control panels.
· Suitable for OEM machine builders and system integrators.
· Designed for Siemens SIMATIC S7-1500 automation architectures.
