Siemens SIMATIC S7-1500 Digital Output Module – 6ES7522-1BH10-0AA0
The Siemens SIMATIC S7-1500 Digital Output Module – 6ES7522-1BH10-0AA0 is a digital output module designed for integration with SIMATIC S7-1500 PLC systems. It provides 16 digital outputs for 24 V DC loads, with an output current capability of 0.5 A per channel, making it suitable for industrial automation systems requiring reliable switching and control of digital field devices.
The 6ES7522-1BH10-0AA0 is a DQ 16xDC 24 V/0.5 A BA module with 16 channels arranged in groups of 8. Each output group supports a maximum current of 4 A per group.
A key feature of this module is its support for the safety-oriented shutdown of load groups up to SIL 2 according to EN IEC 62061:2021 and Category 3 / PL d according to EN ISO 13849-1:2015, when used within an appropriately designed and validated safety system.
The module is supplied with a Push-in front connector, providing convenient wiring for industrial control panels and automation cabinets.
The Siemens 6ES7522-1BH10-0AA0 is suitable for OEM machine builders, system integrators, panel manufacturers, automation engineers, and industrial users requiring dependable digital output control in SIMATIC S7-1500 PLC applications.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SIMATIC S7-1500
· Module Type: Digital Output Module
· Order Number: 6ES7522-1BH10-0AA0
· Output Type: DQ 16xDC 24 V/0.5 A BA
· Number of Digital Outputs: 16
· Output Voltage: 24 V DC
· Output Current: 0.5 A per channel
· Channel Configuration: 16 channels in groups of 8
· Maximum Current per Group: 4 A
· Safety-Oriented Shutdown: Supported up to SIL 2
· Safety Standard: EN IEC 62061:2021
· Performance Level: Category 3 / PL d
· Performance Standard: EN ISO 13849-1:2015
· Front Connector: Included
· Connection Technology: Push-in
· PLC System: SIMATIC S7-1500
· Application: Industrial automation and digital load control
TECHNICAL FEATURES
1. SIMATIC S7-1500 Digital Output Module
The 6ES7522-1BH10-0AA0 belongs to the Siemens SIMATIC S7-1500 automation platform and provides digital output functionality for suitable S7-1500 PLC configurations.
2. 16 Digital Outputs
The module provides 16 digital output channels, allowing the PLC to control multiple connected digital loads from a single I/O module.
3. 24 V DC Output Voltage
The outputs are designed for 24 V DC applications, making the module suitable for controlling compatible industrial loads and field devices.
4. 0.5 A Output Current per Channel
Each digital output provides an output current capability of 0.5 A, supporting suitable 24 V DC loads within the specified operating conditions.
5. Channels in Groups of 8
The 16 digital outputs are arranged in groups of 8, providing the specified electrical organization for field wiring and load management.
6. 4 A Current per Output Group
Each output group supports a maximum current of 4 A, providing the specified group-level load capability for suitable applications.
7. Safety-Oriented Load Group Shutdown
The module supports the safety-oriented shutdown of load groups up to SIL 2 according to EN IEC 62061:2021.
It also supports Category 3 / Performance Level d (PL d) according to EN ISO 13849-1:2015, when incorporated into an appropriately engineered and validated safety-related system.
8. Push-in Front Connector
The module is supplied with a front connector using Push-in connection technology, simplifying field wiring and installation within automation panels.
9. High-Density Digital Output Configuration
With 16 digital outputs, the module provides a compact solution for controlling multiple 24 V DC loads while helping optimize I/O space within an S7-1500 control system.
10. Industrial PLC Integration
The module can be integrated into suitable SIMATIC S7-1500 PLC architectures for machine control, production automation, material handling, process applications, and other industrial systems.
