Siemens SIMATIC S7-1500 DQ 16 × 24 V DC/0.5 A BA Digital Output Module – 6ES7522-1BH10-0AA0
The Siemens 6ES7522-1BH10-0AA0 provides 16 digital output channels for compatible SIMATIC S7-1500 PLC systems. Rated at 24 V DC, 0.5 A per channel, its outputs are arranged in two groups of eight, with 4 A per group. The module supports the specified safety-oriented shutdown of load groups and includes a push-in front connector for field wiring.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SIMATIC S7-1500
· Order Number: 6ES7522-1BH10-0AA0
· Product Type: Digital Output Module
· Module Designation: DQ 16 × 24 V DC/0.5 A BA
· Digital Outputs: 16 channels
· Output Voltage: 24 V DC
· Output Current: 0.5 A per channel
· Channel Grouping: 8 channels per group
· Number of Output Groups: 2
· Current per Group: 4 A
· Included Accessory: Push-in front connector
FEATURES
· 16 Control Connections: Add switching points for suitable machine loads and equipment-control circuits.
· Two Output Groups: Support load allocation across two defined groups of eight channels.
· Specified Electrical Limits: Provide channel and group ratings for checking connected-load requirements.
· Push-in Terminals: The supplied front connector supports field-wire termination.
· Programmed Output Actions: Operate connected devices according to logic executed by the compatible PLC CPU.
BENEFITS
· Adds 16 output channels through one module.
· Includes the push-in front connector in the delivery.
· Provides defined grouping for organizing connected output loads.
· Supports machine extensions requiring additional controlled devices.
