Siemens SIMATIC S7-1500 DQ 16xDC 24V/0.5A BA – 6ES7522-1BH10-0AA0
The Siemens SIMATIC S7-1500 Digital Output Module DQ 16xDC 24V/0.5A BA – 6ES7522-1BH10-0AA0 is a reliable digital output module designed for industrial automation, machine control, production lines, manufacturing systems, control panels, OEM machinery, and actuator control applications.
This 16-channel digital output module provides 24 V DC outputs with 0.5 A per channel and is arranged in groups of 8 channels. Each group supports up to 4 A, making the module suitable for controlling multiple compatible industrial loads and actuators within an S7-1500 automation system.
The module supports the safety-oriented shutdown of load groups up to SIL2 according to EN IEC 62061:2021 and Category 3 / PL d according to EN ISO 13849-1:2015 when used as part of an appropriately designed and validated safety system.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SIMATIC S7-1500
· Module Type: Digital Output Module
· Order Number: 6ES7522-1BH10-0AA0
· Module Designation: DQ 16xDC 24V/0.5A BA
· Digital Outputs: 16 channels
· Output Voltage: 24 V DC
· Output Current: 0.5 A per channel
· Channel Configuration: 16 channels in groups of 8
· Current per Group: 4 A
· Safety-Oriented Shutdown: Supported
· Safety Level: Up to SIL2 according to EN IEC 62061:2021
· Performance Level: Category 3 / PL d according to EN ISO 13849-1:2015
· Front Connector: Included
· Connector Type: Push-in
· PLC Platform: SIMATIC S7-1500
· Application: Industrial automation and digital actuator control
TECHNICAL FEATURES
1. 16-Channel Digital Output Module
The 6ES7522-1BH10-0AA0 provides 16 digital output channels, allowing the S7-1500 PLC to control multiple compatible industrial loads and actuators.
2. 24 V DC / 0.5 A Outputs
Each digital output is specified for 24 V DC and 0.5 A, making the module suitable for a range of compatible industrial digital loads and actuator interfaces.
3. Channels in Groups of 8
The 16 output channels are arranged in groups of 8, providing an organized output architecture for industrial control-panel applications.
4. 4 A Per Group
Each group supports up to 4 A, providing output capacity for multiple connected loads within the specified system requirements.
5. Safety-Oriented Load Shutdown
The module supports safety-oriented shutdown of load groups up to SIL2 according to EN IEC 62061:2021.
It also supports Category 3 / Performance Level d according to EN ISO 13849-1:2015, when incorporated into a suitably designed and validated safety system.
6. Push-in Front Connector Included
The module is delivered including a Push-in front connector, helping simplify field wiring, panel installation, commissioning, and maintenance.
7. SIMATIC S7-1500 Integration
The module is designed for the Siemens SIMATIC S7-1500 platform and can be used to expand digital output capability for PLC-controlled industrial equipment.
