Siemens SIMATIC S7-1500 Digital Output Module – 6ES7522-1BL01-0AB0
The Siemens SIMATIC S7-1500 Digital Output Module – 6ES7522-1BL01-0AB0 is a high-performance digital output module designed for integration with SIMATIC S7-1500 PLC systems. It provides 32 digital outputs for 24 V DC loads, with an output current capability of 0.5 A per channel, making it suitable for industrial automation applications requiring reliable and detailed digital load control.
The 6ES7522-1BL01-0AB0 is a DQ 32x24 V DC/0.5 A HF module with 32 channels arranged in groups of 8. Each group supports a maximum current of 4 A.
This high-feature module provides single-channel diagnostics, a substitute-value function, and a switching-cycle counter for connected actuators, helping support enhanced monitoring and maintenance of connected loads.
The module also supports the safety-oriented shutdown of load groups up to SIL 2 according to EN IEC 62061:2021 and Category 3 / PL d according to EN ISO 13849-1:2015, when incorporated into an appropriately engineered and validated safety system.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SIMATIC S7-1500
· Module Type: Digital Output Module
· Order Number: 6ES7522-1BL01-0AB0
· Module Designation: DQ 32x24 V DC/0.5 A HF
· Number of Digital Outputs: 32
· Output Voltage: 24 V DC
· Output Current: 0.5 A per channel
· Channel Configuration: 32 channels in groups of 8
· Maximum Current per Group: 4 A
· Diagnostics: Single-channel diagnostics
· Substitute Value: Supported
· Switching Cycle Counter: Available for connected actuators
· Safety-Oriented Shutdown: Supported up to SIL 2
· Safety Standard: EN IEC 62061:2021
· Performance Level: Category 3 / PL d
· Standard: EN ISO 13849-1:2015
· Front Connector: To be ordered separately
· Connector Options: Screw terminals or Push-in
· PLC System: SIMATIC S7-1500
· Application: Industrial automation and digital load control
BENEFITS
· 32 digital outputs for high-density industrial control.
· 24 V DC output voltage.
· 0.5 A output current per channel.
· 4 A maximum current per group.
· Channels arranged in groups of 8.
· Single-channel diagnostics for improved troubleshooting.
· Substitute-value function for suitable operating conditions.
· Switching-cycle counter for connected actuators.
· Supports safety-oriented load-group shutdown up to SIL 2.
· Supports Category 3 / PL d according to the specified safety standard.
· Compatible front connector options include screw terminals or Push-in.
· Front connector can be selected and ordered separately.
· Designed for SIMATIC S7-1500 PLC systems.
· Suitable for OEM, machine-building, and industrial automation applications.
