6ES7522-1BL01-0AB0 IN MUMBAI
Siemens SIMATIC S7-1500 Digital Output Module – 6ES7522-1BL01-0AB0
The Siemens SIMATIC S7-1500 Digital Output Module – 6ES7522-1BL01-0AB0 is a high-density digital output module designed for integration into SIMATIC S7-1500 automation systems. It provides 32 digital outputs for 24 V DC loads, with an output current capability of 0.5 A per channel, making it suitable for industrial machine control, actuator switching, production automation, and control-panel applications.
The 6ES7522-1BL01-0AB0 features 32 channels arranged in groups of 8, with a maximum current of 4 A per group. The module provides single-channel diagnostics, a substitute value function, and a switching-cycle counter for connected actuators, supporting monitoring, troubleshooting, and maintenance functions in suitable automation applications.
The module also supports the safety-oriented shutdown of load groups up to SIL2 according to EN IEC 62061:2021 and Category 3 / PL d according to EN ISO 13849-1:2015, when implemented as part of an appropriately designed and validated safety-related system.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SIMATIC S7-1500
· Module Type: Digital Output Module
· Order Number: 6ES7522-1BL01-0AB0
· Output Type: DQ
· Digital Outputs: 32 channels
· Output Voltage: 24 V DC
· Output Current: 0.5 A per channel
· Channel Configuration: 32 channels in groups of 8
· Current per Group: 4 A
· Diagnostics: Single-channel diagnostics
· Substitute Value: Supported
· Actuator Monitoring: Switching-cycle counter for connected actuators
· Safety-Oriented Shutdown: Supported for load groups up to SIL2
· Safety Standard: EN IEC 62061:2021
· Performance Level: Category 3 / PL d
· Safety Standard: EN ISO 13849-1:2015
· Front Connector: Ordered separately
· Connector Options: Screw terminal or Push-in
· System: SIMATIC S7-1500
· Location: Mumbai, Maharashtra, India
BENEFITS
· 32 digital outputs for high-density industrial automation.
· 24 V DC output voltage for compatible field devices.
· 0.5 A output current per channel.
· 4 A maximum current per group.
· Channels arranged in groups of 8.
· Single-channel diagnostics for easier troubleshooting.
· Substitute-value functionality for suitable operating conditions.
· Switching-cycle counter for connected actuators.
· Supports safety-oriented load-group shutdown up to SIL2.
· Supports Category 3 / PL d safety-oriented applications.
· Designed according to the specified EN IEC 62061:2021 requirements.
· Supports the specified EN ISO 13849-1:2015 safety category.
· Compatible front connector options include screw terminal and push-in.
· Suitable for OEM machine builders and system integrators.
· Designed for Siemens SIMATIC S7-1500 automation architectures.
