SIEMENS SIMATIC S7-1500 DQ 32x24 V DC/0.5A HF — 6ES7522-1BL01-0AB0
6ES7522-1BL01-0AB0 is a SIMATIC S7-1500 Digital Output Module (DQ 32x24 V DC/0.5A HF) designed for reliable and diagnostic-capable digital output control in industrial automation systems. With 32 digital output channels, grouped in sets of 8, it provides flexible actuator control for machines, production lines, control panels, and automated manufacturing equipment.
PRODUCT DETAILS
· Product: SIMATIC S7-1500 Digital Output Module
· Order Number: 6ES7522-1BL01-0AB0
· Module Type: DQ 32x24 V DC/0.5A HF
· Number of Outputs: 32 digital outputs
· Output Voltage: 24 V DC
· Output Current: 0.5 A per channel
· Channel Grouping: 32 channels in groups of 8
· Current per Group: 4 A
· Diagnostics: Single-channel diagnostics
· Substitute Value: Supported
· Switching Cycle Counter: Available for connected actuators
· Safety Function: Supports safety-oriented shutdown of load groups
· Safety Level: Up to SIL 2 according to EN IEC 62061:2021
· Performance Level: Category 3 / PL d according to EN ISO 13849-1:2015
· Front Connector: To be ordered separately
· Connector Options: Screw terminals or Push-in
FEATURES
32-Channel Digital Output Control
Provides 32 × 24 V DC digital outputs for controlling industrial actuators, contactors, relays, valves, lamps, solenoids and other automation devices.
High-Functionality HF Module
The HF version incorporates advanced diagnostic functions to help monitor individual output channels and improve system troubleshooting.
Single-Channel Diagnostics
Channel-specific diagnostics can help identify output-related faults, making maintenance and fault localization more efficient.
Switching Cycle Counter
The integrated switching cycle counter allows monitoring of switching operations for connected actuators. This can support condition monitoring and maintenance planning.
Substitute Value Function
The substitute value function provides additional flexibility when outputs need to assume predefined states during specific operating or fault conditions.
Safety-Oriented Load Shutdown
The module supports safety-oriented shutdown of load groups up to SIL 2 and Category 3 / PL d, when implemented within an appropriately designed safety system.
APPLICATIONS
· Industrial machine automation
· Manufacturing and assembly lines
· Conveyor systems
· Packaging machinery
· Process equipment
· Material handling systems
· Automated production plants
· Control cabinets and electrical panels
· Motor and actuator control
· Solenoid and valve control
· Relay and contactor control
· Machine safety applications
