6ES7522-1BL10-0AA0 IN ANKLESHWAR
Siemens SIMATIC S7-1500 DQ 32x24 V DC / 0.5 A BA – 6ES7522-1BL10-0AA0
The Siemens SIMATIC S7-1500 Digital Output Module DQ 32x24 V DC / 0.5 A BA – 6ES7522-1BL10-0AA0 is a high-density digital output module designed for industrial automation, machine control, production lines, manufacturing plants, industrial control panels, OEM machinery, actuator control, and digital output applications.
This 32-channel digital output module provides 24 V DC outputs with an output current rating of 0.5 A per channel. The 32 outputs are arranged in groups of 8 channels, with a maximum current of 4 A per group, providing a structured solution for controlling multiple industrial loads.
The 6ES7522-1BL10-0AA0 also supports the safety-oriented shutdown of load groups up to SIL2 according to EN IEC 62061:2021 and Category 3 / PL d according to EN ISO 13849-1:2015, when incorporated into an appropriately designed and validated safety-related system.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SIMATIC S7-1500
· Module Type: Digital Output Module
· Order Number: 6ES7522-1BL10-0AA0
· Module Designation: DQ 32xDC 24 V / 0.5 A BA
· Digital Outputs: 32 channels
· Output Voltage: 24 V DC
· Output Current: 0.5 A per channel
· Channel Configuration: 32 channels in groups of 8
· Maximum Current per Group: 4 A
· Safety-Oriented Shutdown: Supported up to SIL2
· Safety Standard: EN IEC 62061:2021
· Performance Level: Category 3 / PL d
· Safety Standard: EN ISO 13849-1:2015
· Front Connector: Included
· Connector Type: Push-in
· PLC Platform: SIMATIC S7-1500
· Application: Industrial digital output and actuator control
BENEFITS
· Siemens SIMATIC S7-1500 digital output module
· 32 × 24 V DC digital outputs
· 0.5 A output per channel
· 32 outputs arranged in groups of 8
· 4 A maximum current per output group
· Supports safety-oriented load-group shutdown up to SIL2
· Supports Category 3 / PL d applications when properly designed and validated
· EN IEC 62061:2021 support
· EN ISO 13849-1:2015 support
· Push-in front connector included
· Convenient panel wiring and installation
· High-density digital output solution
· Suitable for industrial actuator control
· Suitable for machine and factory automation
· Suitable for OEM machine builders
· Suitable for control-panel manufacturers
· Useful for system integrators
· Suitable for manufacturing and industrial plants
· Supports structured load-group control
