6ES7522-1BL10-0AA0 IN KALINGANAGAR
Siemens SIMATIC S7-1500 DQ 32 × 24 V DC/0.5 A BA Digital Output Module – 6ES7522-1BL10-0AA0
The Siemens 6ES7522-1BL10-0AA0 expands compatible SIMATIC S7-1500 systems with 32 digital outputs rated at 24 V DC, 0.5 A per channel. Outputs are arranged in four groups of eight channels, with 4 A per group. The module supports safety-oriented shutdown of load groups within the stated safety classifications and is supplied with a push-in front connector.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SIMATIC S7-1500
· Order Number: 6ES7522-1BL10-0AA0
· Module Type: Digital Output Module
· Module Designation: DQ 32 × 24 V DC/0.5 A BA
· Digital Output Channels: 32
· Output Voltage: 24 V DC
· Output Current: 0.5 A per channel
· Channel Grouping: 8 channels per group
· Number of Output Groups: 4
· Current per Group: 4 A
· Supported Load-Group Shutdown: Up to SIL 2 and Category 3 / PL d
· Included Connection Component: Push-in front connector
OUTPUT CONTROL
· 32 Switching Points: Provide connections for suitable machine devices, indicators, and control circuits.
· Eight-Channel Groups: Organize output loads into four defined groups for electrical planning.
· Channel and Group Ratings: Support load selection using both the 0.5 A channel rating and 4 A group limit.
· Push-in Connections: The included front connector provides push-in terminals for field wiring.
BENEFITS
· Adds 32 digital output channels through one module.
· Supports applications with multiple independently commanded devices.
· Provides defined output grouping for allocating connected loads.
· Includes the front connector needed for field-wire termination.
APPLICATIONS
· Machine Status Displays: Operate compatible 24 V DC indicator lamps.
· Interface Relays: Switch suitable relay coils with appropriate protection.
· Pneumatic Controls: Activate compatible solenoid valve coils within channel and group limits.
· Equipment Commands: Send switching signals to suitable connected control inputs.
· Multi-Station Machinery: Distribute programmed output actions across assembly, packaging, or handling stations.
