6ES7522-1BL10-0AA0
Siemens 6ES7522-1BL10-0AA0 – S7-1500 Digital Output Module
The Siemens 6ES7522-1BL10-0AA0 is a SIMATIC S7-1500 DQ32xDC 24 V / 0.5 A BA digital output module engineered for high-density actuator and load control in industrial automation systems. With 32 digital output channels, the module provides efficient control of multiple 24 V DC loads from a single PLC station.
The outputs are divided into groups of 8 channels, with each group supporting a maximum current of 4 A. The module also incorporates support for safety-oriented shutdown of load groups up to SIL 2 according to EN IEC 62061:2021 and Category 3 / PL d according to EN ISO 13849-1:2015.
Technical Data
· Order Number: 6ES7522-1BL10-0AA0
· Series: SIMATIC S7-1500
· Module: Digital Output Module
· Output Configuration: DQ32xDC 24 V / 0.5 A BA
· Digital Outputs: 32 channels
· Output Voltage: 24 V DC
· Rated Current: 0.5 A per output
· Channel Arrangement: 4 groups × 8 channels
· Maximum Group Current: 4 A
· Safety Shutdown: Up to SIL 2
· Safety Category: Category 3 / PL d
· Front Connector: Push-in
· Front Connector Included: Yes
Benefits
High Output Density:
32 digital outputs allow numerous field devices to be controlled from one compact S7-1500 module.
Efficient Load Distribution:
The 8-channel grouping simplifies power distribution and machine wiring.
24 V DC Industrial Control:
Suitable for switching compatible actuators, contactors, valves, indicators and other automation loads.
Safety-Oriented Design:
Support for safety-oriented load-group shutdown makes the module suitable for automation architectures requiring defined safety functions within the specified limits.
Easy Panel Installation:
The included push-in front connector enables convenient field wiring and maintenance.
Features
- 32-channel digital output configuration for high-density control applications.
- 24 V DC outputs suitable for common industrial control devices.
- 0.5 A per output channel for controlling suitable loads.
- Channels are organized into four groups of 8 outputs.
- Supports up to 4 A per output group.
- Supports safety-oriented shutdown of load groups up to SIL 2 according to EN IEC 62061:2021.
- Supports Category 3 / PL d according to EN ISO 13849-1:2015.
- Push-in front connector included, simplifying panel wiring and installation.
- Designed for integration into SIMATIC S7-1500 PLC systems.
