6FX3002-5BL03-1AD0
Siemens MOTION-CONNECT 300 Motor Brake Cable – 6FX3002-5BL03-1AD0
The Siemens MOTION-CONNECT 300 – 6FX3002-5BL03-1AD0 is a 3-metre pre-assembled brake cable for compatible SIMOTICS S-1FL6 HI 400 V motors used with SINAMICS V70/V90 systems. It features 2 × 0.75 mm² conductors, a straight motor-side connector, and a maximum cable diameter of 6.3 mm for the specified motor brake connection.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: MOTION-CONNECT 300
· Order Number: 6FX3002-5BL03-1AD0
· Product Type: Pre-assembled Brake Cable
· Conductor Configuration: 2 × 0.75 mm²
· Motor Compatibility: SIMOTICS S-1FL6 HI 400 V
· System Compatibility: SINAMICS V70/V90
· Cable Length: 3 m
· Maximum Cable Diameter: 6.3 mm
· Motor-Side Connector: Straight
· UL Approval: No UL approval
FEATURES
· Dedicated Brake Wiring: Provides a cable connection for the brake circuit of the specified compatible motor.
· Pre-assembled Construction: Reduces onsite preparation of the motor-side connection.
· Two-Conductor Design: Incorporates two conductors with a cross-section of 0.75 mm² each.
· Straight Connector: Suits installations requiring a straight connection at the motor.
· 3-Metre Length: Provides a fixed-length option where the complete cable route fits within the supplied length.
BENEFITS
· Offers a defined brake cable option for compatible S-1FL6 HI motor installations.
· Helps plan routing space using the specified 6.3 mm maximum diameter.
· Simplifies replacement selection through the exact Siemens order number.
· Supports installation planning with known conductor size, length, and connector arrangement.
APPLICATION
· Use with the compatible motor’s brake connection and suitable brake-control equipment.
· Confirm the exact S-1FL6 HI motor and V70/V90 system configuration.
· Allow space for the straight motor-side connector and the required cable bends.
· Check that the 3-metre length covers the planned routing path.
· Select for applications where UL approval is not required.
