6FX3002-5CL02-1CA0
Siemens MOTION-CONNECT 300 Motor Power Cable – 6FX3002-5CL02-1CA0
The Siemens MOTION-CONNECT 300 – 6FX3002-5CL02-1CA0 is a pre-assembled power cable for compatible SIMOTICS S-1FL6 HI 400 V motors used with SINAMICS V70/V90 frame size AA. Featuring four 1.5 mm² conductors, a 20-metre length, and a straight motor-side connector, it supports motor power connections where a longer cable route is required.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: MOTION-CONNECT 300
· Order Number: 6FX3002-5CL02-1CA0
· Product Type: Pre-assembled Motor Power Cable
· Conductor Configuration: 4 × 1.5 mm²
· Motor Compatibility: SIMOTICS S-1FL6 HI 400 V
· Drive Compatibility: SINAMICS V70/V90, frame size AA
· Cable Length: 20 m
· Maximum Cable Diameter: 8.1 mm
· Motor-Side Connector: Straight
· UL Approval: No UL approval
FEATURES
· Pre-assembled Construction: Reduces the need for onsite motor-side connector assembly.
· 20-Metre Cable Length: Accommodates installations with greater routing distance between the drive cabinet and motor.
· Straight Connector Arrangement: Suits motor connections requiring a straight cable exit.
· Defined Cable Diameter: The 8.1 mm maximum diameter helps with planning cable passages and routing space.
· Specified Motor and Drive Pairing: Supports cable selection for the stated S-1FL6 HI and V70/V90 combination.
ADVANTAGES
· Provides a ready-made cable option for compatible motor power connections.
· Helps plan equipment layouts using a specified cable length and diameter.
· Offers a defined conductor size for checking against the application’s electrical requirements.
· Suits new installations or replacement work requiring this exact cable configuration.
SYSTEM SELECTION POINTS
· Match the cable to the compatible S-1FL6 HI 400 V motor and V70/V90 frame size AA drive.
· Confirm that the 20-metre length meets the routing requirement and the drive’s permitted cable-length limits.
· Allow sufficient clearance for the straight motor-side connector.
· Check that the 4 × 1.5 mm² conductors meet the selected motor and drive requirements.
· Use where UL approval is not required.
