6SL3210-1PE27-5UL0
Siemens SINAMICS G120 PM240-2 Power Module – 6SL3210-1PE27-5UL0
The Siemens SINAMICS G120 PM240-2, 6SL3210-1PE27-5UL0 is a high-performance power module designed for demanding industrial drive applications requiring reliable motor control, high overload capability, and regenerative braking support. This FSD, IP20 Power Module operates on a 3-phase 380–480 V AC supply and includes a built-in braking chopper for applications requiring controlled deceleration.
The module supports 30 kW High Overload (HO) operation and 37 kW Low Overload (LO) operation, making it suitable for machines with different load-duty requirements. It is supplied without a filter, Control Unit, and operator panel, allowing the drive system to be configured according to the specific automation architecture.
PRODUCT SPECIFICATIONS
Product Family : SINAMICS G120
Product Type : PM240-2 Power Module
Article Number : 6SL3210-1PE27-5UL0
Input Voltage : 3AC 380–480 V +10% / -20%
Frequency : 47–63 Hz
High Overload Power : 30 kW
HO Overload Capacity : 200% for 3 s, 150% for 57 s, 100% for 240 s
HO Ambient Temperature : -20°C to +50°C
Low Overload Power : 37 kW
LO Overload Capacity : 150% for 3 s, 110% for 57 s, 100% for 240 s
LO Ambient Temperature : -20°C to +40°C
Protection Rating : IP20
Frame Size : FSD
Dimensions (H × W × D) : 472 × 200 × 237 mm
Braking Chopper : Built-in
Filter : Without filter
Control Unit : Not included
Operator Panel : Not included
Approved CU Firmware : V4.7 HF8
Application : Industrial motor and machine drive systems
TECHNICAL HIGHLIGHTS
1. Dual Duty-Class Operation
The 6SL3210-1PE27-5UL0 provides two defined operating ratings:
- 30 kW High Overload (HO) for applications with higher dynamic load requirements.
- 37 kW Low Overload (LO) for applications where the motor operates with comparatively lower overload demand.
This makes the Power Module adaptable to different machine load profiles.
2. Built-In Braking Chopper
The integrated braking chopper supports applications where the motor must decelerate rapidly. It allows connection to a suitable external braking resistor for handling braking energy during demanding deceleration cycles.
3. Wide Industrial Voltage Range
Designed for 3-phase 380–480 V AC, the module accommodates a broad industrial supply range with +10% / -20% voltage tolerance, supporting installation across common industrial electrical networks.
4. High Overload Capability
For demanding applications, the HO rating provides:
200% for 3 seconds → 150% for 57 seconds → 100% for 240 seconds
This makes it suitable for machines experiencing short-duration starting, acceleration, or load peaks.
5. FSD Mechanical Design
The Frame Size FSD construction provides a compact industrial form factor while supporting the 30/37 kW power class.
6. IP20 Protection
The IP20 enclosure is intended for installation inside suitable electrical control cabinets or protected industrial enclosures.
7. Modular G120 Architecture
The Power Module is part of the modular SINAMICS G120 platform. Because the Control Unit and operator panel are not included, system designers can select the appropriate control architecture separately.
