SIEMENS SINAMICS G120 PM240-2 POWER MODULE – 6SL3210-1PE31-5UL0

6SL3210-1PE31-5UL0 is a Siemens SINAMICS G120 PM240-2 Power Module designed for demanding industrial drive applications. It supports 3-phase 380–480 V AC input and provides 55 kW High Overload (HO) and 75 kW Low Overload (LO) operation. The module includes a built-in braking chopper and is supplied without a control unit, operator panel, and line filter.

PRODUCT DETAILS

·        Product: SINAMICS G120 Power Module PM240-2

·        Order Number: 6SL3210-1PE31-5UL0

·        Series: SINAMICS G120

·        Power Module: PM240-2

·        Input Voltage: 3AC 380–480 V

·        Voltage Tolerance: +10% / -20%

·        Frequency: 47–63 Hz

·        High Overload Rating: 55 kW

·        Low Overload Rating: 75 kW

·        Braking Chopper: Built-in

·        Line Filter: Without filter

·        Protection Rating: IP20

·        Frame Size: FSF

·        Dimensions (H × W × D): 708 × 305 × 357 mm

·        Ambient Temperature – HO: -20 to +50 °C

·        Ambient Temperature – LO: -20 to +40 °C

·        Control Unit: Not included

·        Operator Panel: Not included

·        Firmware Compatibility: Approved for CU firmware version V4.7 HF8

OVERLOAD PERFORMANCE

High Overload (HO) – 55 kW

·        200% for 3 seconds

·        150% for 57 seconds

·        100% for 240 seconds

·        Ambient temperature: -20 to +50 °C

Low Overload (LO) – 75 kW

·        150% for 3 seconds

·        110% for 57 seconds

·        100% for 240 seconds

·        Ambient temperature: -20 to +40 °C

FEATURES

·        High-power SINAMICS G120 PM240-2 power module

·        Suitable for 55 kW HO / 75 kW LO applications

·        Integrated braking chopper for dynamic braking applications

·        380–480 V three-phase supply

·        Robust IP20 enclosure

·        FSF frame size for high-power drive installations

·        Designed for integration with a compatible SINAMICS G120 Control Unit

·        Suitable for demanding industrial motor-control applications
