6SL3210-5FE17-0UF0
Siemens SINAMICS V90 PROFINET Servo Drive – 6SL3210-5FE17-0UF0
The Siemens SINAMICS V90 – 6SL3210-5FE17-0UF0 is a PROFINET-equipped servo drive for compatible 7.0 kW motors. Operating from a 380–480 V three-phase supply, it provides a 13.2 A rated output current and an output frequency range of 0–330 Hz. Its size C housing and IP20 protection rating support integration into a suitable industrial control cabinet.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SINAMICS V90
· Order Number: 6SL3210-5FE17-0UF0
· Product Type: Servo Drive
· Communication Interface: PROFINET
· Input Voltage: 380–480 V AC, three-phase
· Input Voltage Tolerance: −15% / +10%
· Input Current: 16.5 A
· Input Frequency: 45–66 Hz
· Output Voltage: 0 V up to input voltage
· Output Current: 13.2 A
· Output Frequency: 0–330 Hz
· Motor Power Rating: 7.0 kW
· Degree of Protection: IP20
· Frame Size: C
· Dimensions: 140 × 260 × 240 mm (W × H × D)
FEATURES
· PROFINET Connectivity: Supports integration with compatible controllers for network-based drive commands and status exchange.
· 7.0 kW Motor Application: Provides a drive option for appropriately matched servo motors in this power class.
· Three-Phase Supply: Accepts the specified 380–480 V AC input within its stated tolerance.
· Variable Motor Output: Supplies controlled output voltage and frequency according to the drive’s operation.
· Size C Construction: Provides defined housing dimensions for cabinet layout planning.
BENEFITS
· Connects servo-axis operation with the machine’s compatible PROFINET control system.
· Supports coordinated machine sequences through controller-to-drive communication.
· Provides stated electrical ratings for matching the drive, motor, and supply.
· Helps panel builders plan installation space using known frame dimensions.
APPLICATION
· Packaging Machinery: Support suitably sized feeding, indexing, and positioning axes.
· Assembly Systems: Drive compatible servo mechanisms operating within programmed machine sequences.
· Material Handling: Control appropriately selected transfer and movement axes.
· Control Cabinets: Install in a suitable enclosure with the clearances and ventilation required by the drive instructions.
· Motor Matching: Confirm motor compatibility, current requirements, and feedback connections before system selection.
